Home > Product & Solutions > Mobile Rotary Lobe Pumps > Mobile lobe pump

Mobile Rotary Lobe Pumps

Design Features

◆Move to any place where pump material at anytime.
◆Standard configuration: With console, Lockable mobile plate, Mechanical avariable gearbox
◆Option: Console with built-in converter, frequency conversion motor(For more informtion, Please refer to our lobe pump catalogue)

Technical specifications

◆ Maximum flow: 90m3 / H
◆ Maximum pressure: 20bar
◆ Maximum temperature: 150 ℃
◆ Maximum speed: 750 rpm
◆ Material: ASTM 316L, 1.4404
◆ Inside surface: Ra0.8μm
◆ Certificate: 3-A-02-11NO.1579; CE-MD / 06-42; FDA.177.2600
◆ Horizontal TUL
◆ Vertical TUR
◆ butterfly rotor (standard)
◆ Mechanical seal: Single mechanical seal (standard) double mechanical seal (option) Material SIC / SIC, TC / TC
◆ Suitable for CIP cleaning and SIP sterilization









Download catalogue
